HydroQuip Squareback 26-3236-1A-5T-K: Premium Low Flow Titanium Heater
Product Overview
As a retailer of hot tub spare parts, I’m featuring the HydroQuip Squareback Low Flow Heater, a versatile 4.0kW heating solution featuring a titanium element and dual voltage capability. This specialized heater is designed as a direct replacement for various premium spa brands including Artesian, Atera, and LA Spas.
Key Features
- Premium titanium heating element
- Dual voltage capability (115V/230V)
- Squareback design for specific applications
- Extended 26″ cord with pigtail ends
- Pressure switch tap
- Low flow optimization
Technical Specifications
| Specification | Detail |
|---|---|
| Model Number | 26-3236-1A-5T-K |
| Heater Type | Squareback Low Flow |
| Power Rating | 4.0kW |
| Voltage | 115V/230V Convertible |
| Water Connection Size | 1″ Barb Inlet/Outlet |
| Overall Dimensions | 26″ x 14″ |
| Tube Size | 1″ |
| Element Material | Titanium |
| Cord Length | 26″ Pigtail |
| Replaces Models | C-3236-1A, 6739 Series |
Premium Construction
Titanium element benefits:
- Superior corrosion resistance
- Extended service life
- Enhanced durability
- Optimal heat transfer
Installation Features
Professional design includes:
- Squareback mounting configuration
- Integrated pressure switch tap
- Flexible pigtail connections
- Universal voltage options
Brand Compatibility
Direct replacement for:
- Artesian Spas
- Atera Systems
- LA Spas
- Compatible trombone heater systems
Performance Characteristics
Engineered for efficiency:
- Optimized low flow operation
- Dual voltage flexibility
- Consistent heating control
- Reliable performance
Alternate Part Numbers
- C-3236-1A
- C3236-1A
- 6739
Hot Tub Heater Element Replacement; What are the symptoms a hot tub heater element needs replacing?
There are several symptoms that may indicate a hot tub heater element needs replacing. Here are some common signs to watch out for:
Inadequate Heating:
If you notice that your hot tub water is not reaching the desired temperature or is taking much longer to heat up than usual, it could be a sign of a failing heater element. The element may not be generating enough heat or may be malfunctioning, resulting in insufficient heating of the water.
Fluctuating Temperature:
If the hot tub water temperature fluctuates inconsistently, going from hot to cold or vice versa, it could indicate a problem with the heater element. It may be struggling to maintain a steady temperature due to a damaged or faulty element.
No Heating: If your hot tub water remains cold even when the heater is running, it’s likely that the heater element has failed completely. This can occur due to a burnt-out element or a break in the electrical connection.
Tripping Breakers:
If the hot tub’s electrical breaker frequently trips or the GFCI (Ground Fault Circuit Interrupter) is constantly triggered, it could be a sign of a faulty heater element. Electrical issues within the element can cause short circuits or excessive power draw, leading to breaker trips.
Visible Damage:
Inspect the heater element visually for any visible signs of damage, such as cracks, breaks, or corrosion. Physical damage to the element can affect its performance and reliability.
It’s important to note that these symptoms can also be indicative of other hot tub issues, such as problems with the thermostat or the control board. Therefore, it’s recommended to consult a hot tub professional or refer to the manufacturer’s troubleshooting guide to accurately diagnose the cause of the problem.
If you suspect that the heater element is the culprit behind the issues you’re experiencing, it may be necessary to replace the element. Consult the manufacturer’s guidelines and specifications to ensure you select the correct replacement element for your hot tub model.
At Parts4Tubs.com, we offer a wide range of hot tub heater elements, including compatible options for various hot tub brands and models. Replacing a faulty heater element will help restore proper heating performance and ensure an enjoyable hot tub experience.
How to Check if you Have a Bad Heating Element
To check if an electric heating element for a water heater is bad, even when it has voltage but isn’t producing heat, you can follow these steps:
- Safety first: Turn off the power to the water heater at the circuit breaker before inspecting or testing the element.
- Access the element: Remove the access panel and insulation to expose the heating element.
- Visual inspection: Look for signs of damage, corrosion, or mineral buildup on the element.
- Continuity test:
- Disconnect the wires from the element terminals.
- Use a multimeter set to the continuity or resistance (ohms) setting.
- Touch one probe to each terminal of the element.
- A reading between 10-30 ohms typically indicates a good element.
- If you get no reading (infinite resistance), the element is likely faulty.
- Ground test:
- Keep one multimeter probe on one of the element terminals.
- Touch the other probe to the metal water heater tank.
- If you get any reading, the element is grounded and needs replacement.
- Voltage test (after reassembling):
- Turn the power back on.
- Set your multimeter to AC voltage.
- Carefully test the voltage across the two terminals.
- You should see the correct voltage (usually 120V or 240V).
If the element passes the continuity test and isn’t grounded, but still isn’t heating, the problem might be with the thermostat or another component of the water heater.
